LED Panel Lighting Range

LED panel lamp is one of the most popular luminaire for commercial lighting, with continuous modification of its design, light efficiency, CRI, UGR and smart function, MyLite Lighting is always capable of providing customers helpful solution and best price, that’s the main reason MyLite Lighting is preferred supplier of LED panel lamp in the market.

MyLite LED panel family supply different solutions for projects and distribution, such us regular LED panel with high Lumen and low UGR, CCT changing LED panel, waterproof led panel, frameless led panel, Up/down emitting led panel, big size round led panel with recessed / surface mounted / pendant installation, TUV-CE approved driver and Lifud, Tridonic, Philips driver ensure our reputation of quality always.

Featured Panel Lighting Ranges:

Waterproof Panel Light

Product Size: 300X300/ 600X600mm
Beam Angle: 120°
Protection Grade: IP54

Framelass Panel Light

Product Size: 300X300/300X600 /600X600/300X1200mm
Protection Grade: IP40

Double Side Emitting

Product Size: 600X600/300X1200/600X1200mm
Protection Grade: IP40

Pendant Panel Light

Product Size: Ø300X12/Ø400X12/Ø500X12/Ø600X1200mm
Protection Grade: IP40

TUV Panel Light

Product Size: 300X300/300X600/600X600/300X1200/600X1200mm
Protection Grade: IP40

Round Panel Light

Product Size: Ø146X21/Ø180X19/Ø200X19/Ø220X19/Ø240X19/Ø300X19mm. Protection Grade: IP40

Batten Light

Specifications:

Name Image    Code   #      Description     Dimension   voltage   POWER BEAM
ANGLE
LUMENS
PL-U (Waterproof)

ML-UP-PL3030-18W-U

*Widely used, suitable for damp location. High Lumen SMD LED chips with excellent color rendering index

300X300mm

200-240V

18W

120°

1240-1300lm

PL-U (Waterproof)

ML-UP-PL6060-45W-U

As Above *

600X600mm

200-240V

45W

120°

3280-3350lm

PL-P (Flameless)

ML-UP-PL3030-18W-P

*Widely used, suitable for damp location. Triac, 0-10V and DALI dimmable. High Lumen SMD LED chips with excellent color rendering index.

300X300mm

200-240V

18W

120°

1240-1300lm

PL-P (Flameless)

ML-UP-PL6060-45W-P

As Above *

600X600mm

200-240V

45W

120°

3400-3900lm

PL30120

ML-UP-PL30120-45W-L

*Double Side Emitting LED Panel. Triac, 0-10V and DALI dimmable. High Lumen SMD LED chips with excellent color rendering index.

200-240V

45W

120°

2800-3500lm

PL6060

ML-UP-PL6060-45W-L

As Above *

200-240V

45W

120°

2700-3400lm

PL60120

ML-UP-PL60120-72W-L

As Above *

200-240V

72W

120°

4600-4900lm

PL40120

ML-UP-PL40120-25W-W

*Widely used, suitable for damp location. Triac dimmable. High Lumen SMD LED chips with excellent color rendering index.

200-240V

25W

120°

2000-2170lm

PL40120

ML-UP-PL40120-35W-W

As Above *

200-240V

35W

120°

2870-3080lm

PL60120

ML-UP-PL60120-35W-W

As Above *

200-240V

35W

120°

2800-3040lm

PL3030

ML-UP-PL3030-18W

*CE, RoHS, SAA, TUV approved. Widely used, suitable for damp location. Triac dimmable. High Lumen SMD LED chips with excellent color rendering index.

200-240V

18W

120°

1100-1300lm

PL3030

ML-UP-PL3030-36W

As Above *

200-240V

36W

120°

2300-2600lm

PL3060

ML-UP-PL3060-36W

As Above *

200-240V

36W

120°

2300-2600lm

PL6060

ML-UP-PL6060-36W

As Above *

200-240V

36W

120°

2330-2650lm

PL6060

ML-UP-PL6060-45W

As Above *

200-240V

45W

120°

2900-3270lm

PL6060

ML-UP-PL6060-56W

As Above *

200-240V

56W

120°

3450-4200lm

PL6262

ML-UP-PL6262-36W

As Above *

200-240V

36W

120°

2300-2650lm

PL6262

ML-UP-PL6262-45W

As Above *

200-240V

45W

120°

2900-3270lm

PL30120

ML-UP-PL30120-45W

As Above *

200-240V

45W

120°

2900-3240lm

PL30120

ML-UP-PL30120-56W

As Above *

200-240V

56W

120°

3450-4100lm

PL30120

ML-UP-PL30120-72W

As Above *

200-240V

72W

120°

4500-4900lm

PL60120

ML-UP-PL60120-45W

As Above *

200-240V

45W

120°

2900-3270lm

PL60120

ML-UP-PL60120-72W

As Above *

200-240V

72W

120°

4890-4900lm

PL14519

ML-UP-PL14519-7W

*CE, RoHS, SAA, TUV approved. Widely used, suitable for damp location. Triac, 0-10V and DALI dimmable. High Lumen SMD LED chips with excellent color rendering index.

Ø146X21mm

200-240V

7W

120°

430-550lm

PL1819

ML-UP-PL1819-10W

As Above *

Ø180X19mm

200-240V

10W

120°

620-780lm

PL2019

ML-UP-PL2019-10W

As Above *

Ø200X19mm

200-240V

10W

120°

620-780lm

PL2219

ML-UP-PL2219-15W

As Above *

Ø200X19mm

200-240V

15W

120°

900-1130lm

PL2419

ML-UP-PL2419-15W

As Above *

Ø240X19mm

200-240V

15W

120°

950-1180lm

PL2419

ML-UP-PL2419-20W

As Above *

Ø240X19mm

200-240V

20W

120°

1060-1460lm

PL3019

ML-UP-PL3019-20W

As Above *

Ø300X19mm

200-240V

20W

120°

1280-1480lm

Batten Light

ML-UP-DB05C-40W

As Above *

1200x90x28 mm

200-240V

40W

120°

3450-3500lm
